XLPE Insulated Cable

MOQ:	300meter
Prijs:	USD 5.25-8.99/M
Standaardverpakking:	Houten trommel
Leveringstermijn:	15 dagen
Betalingswijze:	L/C, T/T,
Toeleveringskapaciteit:	100KM/week

Details Informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst

China

Merknaam

QINGDAO YICABLE CABLE

Certificering

KEMA/CE/ISO/TUV/RoSH

leider:

koper 99.99%

Isolatie:

XLPE

buigen:

12XO.D

Isolatiekleur:

Blauw, Rood, Geel

Werkende Temperaturen:

90 graden

Kabelteken:

Druk of het In reliëf maken

belangrijkste markt:

Aisa

Markeren:

xlpe electrical cable

xlpe power cable

Productbeschrijving

Three Core Copper Conductor XLPE Insulated Medium Voltage 11kV Power Cable

Construction

Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228

Conductor Screen: Semi-conductor

Insulation : XLPE(cross-linked polyethylene) rated at 90 OC

Insulation Screen: Semi-conductor

Screen : Copper tape

Sheath : PVC or FR-PVC type ST2 to IEC 60502, black

Code name:

YJ: XLPE insulation
V: PVC sheath
32:Steel wire armoring—3 cores
22:Steel tape armoring—3 cores
72: Aluminum wire armoring—1 core
62: Stainless steel tape armoring—1 core
ZR: Flame resistant

Application

Used for power transmission and distribution line with voltage rated at 35kV and below.
High and Medium voltage power cable for static application in ground, within and outside facilities, outdoor, in cable canals, in water, in conditions where cables are not exposed to heavier mechanical stress and tensile strain.

Standard

International: IEC 60502, IEC 60228
China: GB/T 12706
Other standards such as BS, DIN and ICEA upon request

Technical data:

Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Sheath Thickness	Approx. O.D.	Approx. Weight	Max. D.C Resistance of Conductor (20 ℃)	Testing Voltage A.C	Current Rating
mm²	pc/mm	mm	mm	(mm)	kg/km	Ω /km	kV/5min	In air (A)	In soil(A)
1 × 25	7/2.14	3.4	2	20.0	598	0.727	21	140	150
1 × 35	7/2.52	3.4	2	22.0	719	0.524	21	175	180
1 × 50	10/2.52	3.4	2	23.0	884	0.387	21	205	215
1 × 70	14/2.52	3.4	2	24.0	1097	0.268	21	260	265
1 × 95	19/2.52	3.4	2	26.0	1378	0.193	21	315	315
1 × 120	24/2.52	3.4	2	28.0	1658	0.153	21	365	360
1 × 150	30/2.52	3.4	2	30.0	1967	0.124	21	415	405
1 × 185	37/2.52	3.4	2	31.0	2335	0.0991	21	475	455
1 × 240	48/2.52	3.4	2	34.0	2908	0.0754	21	565	530
1 × 300	61/2.52	3.4	2	36.0	3507	0.0601	21	645	595
1 × 400	61/2.97	3.4	2.5	39.0	4503	0.0470	21	750	680
1 × 500	61/3.23	3.4	2.5	42.0	5479	0.0366	21	865	765
1 × 630	61/3.50	3.4	2.5	48.0	6952	0.0283	21	990	860
1 × 800	91/3.20	3.4	2.6	52.0	7120	0.0221	21	1140	950
1 × 1000	91/3.75	3.4	2.8	57.0	10500	0.0176	21	1250	1040
3 × 25	7/2.14	3.4	2.3	41.0	895	0.727	21	120	125
3 × 35	7/2.52	3.4	2.4	44.0	2293	0.524	21	145	155
3 × 50	10/2.52	3.4	2.5	46.0	2812	0.387	21	175	180
3 × 70	14/2.52	3.4	2.6	50.0	3508	0.268	21	220	220
3 × 95	19/2.52	3.4	2.7	53.0	4402	0.193	21	265	265
3 × 120	24/2.52	3.4	2.8	56.0	5319	0.153	21	305	300
3 × 150	30/2.52	3.4	2.9	59.0	6309	0.124	21	350	340
3 × 185	37/2.52	3.4	3.0	62.0	7319	0.0991	21	395	380
3 × 240	48/2.52	3.4	3.2	68.0	9218	0.0754	21	470	435
3 × 300	61/2.52	3.4	3.4	72.0	11159	0.0601	21	535	485
3 × 400	61/2.97	3.4	3.6	81.0	15107	0.0470	21	610	520
