3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring
  • Naam
  • Naam
  • Naam
  • Naam

3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring

MOQ: 500
Prijs: USD 1-100 Per Meter
Standaardverpakking: Ijzer-houten trommel of Houten trommel
Leveringstermijn: 15 dagen
Betalingswijze: L/C, T/T, Western Union, MoneyGram
Toeleveringskapaciteit: 1000KM PER MAAND
Details Informatie
Productbeschrijving
Gedetailleerde informatie
Plaats van herkomst
China
Merknaam
QINGDAO YICABLE CABLE
Certificering
IEC/CE/KEMA
Nominale spanning:
0.6/1kV
Dirigent Type:
Vastgelopen Leider (Klasse 2)
Kernteken:
Aantal of Kleurenstrook
Buigende straal:
6D cirkelleiders
Trommellengte:
500m of vanaf verzoek
Max. Werkende Temperatuur:
90℃
Markeren:

xlpe electrical cable

,

cross linked polyethylene cable

Productbeschrijving

3 Core Copper Low Voltage Power Cables For Industrial Wiring and Mains Distribution

Applications: Industrial wiring and mains distribution. Can be laid direct in the ground, or in ducts, clipped to surface, on trays or in free air.



CONSTRUCTION



Conductor : Single, Two, Three, Four and Five core cables. Stranded plain copper conductors Insulation : XLPE insulated, cores laid up, extruded PVC bedding, galvanised steel wire armoured (Aluminium wires for single cores) and PVC sheathed.



STANDARD COLOURS



Cores : Single-core- Red or Black 2-core- Red and Black 3-core- Red, Yellow and Blue 4-core- Red, Yellow, Blue and Black 5-core- Red, Yellow, Blue, Black and Green/Yellow As per New Harmonised Code Single-core- Brown or Blue 2-core- Brown and Blue 3-core- Brown, Black and Grey 4-core- Brown, Black Grey and Blue 5-core- Brown, Black, Grey, Green/Yellow and Blue



PROPERTY:



1.The highest allowed operating temperature of conductor for long-term working is 90 degrees. 2.In short circuit (Max long term is no more than 5 seconds),the highest temperature for conductor is no more than 250 degrees. 3.The cable is laid without horizontal drop limit. The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated. 4.Excellent electrical performance, resistance to chemical corrosion. 5.They can stand advisable traction when laid. They can stand traction from Outside. Left low smoke halogen-free after burned. Retard the burning of the cabl




Ordering Advice

Rated Voltage
Application Standard: IEC/BS/UL/GB
Number of Cores
Conductor Size & Construction
Type of Insulation
Armored or unarmored. If armor, the armor type & material
The Requirement of Sheath
Length of Cable & Packing Requirement
Other Requirement


3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring 0




Tags:

kruis verbonden polyethyleenkabel,

XLPE kabel,

xlpe elektrokabel

Aanbevolen producten
LV CU XLPE Insulated Power Cable Four Core With Aluminum Conductor

LV CU XLPE Insulated Power Cable Four Core With Aluminum Conductor

Contact opnemen
Insulated Power Low Voltage XLPE Cable For Power Distribution / Transmission Line

Insulated Power Low Voltage XLPE Cable For Power Distribution / Transmission Line

Contact opnemen
Armoured / Unarmoured Multicore Power Cable 300 Sq mm Cross Section Area YJVR YJV

Armoured / Unarmoured Multicore Power Cable 300 Sq mm Cross Section Area YJVR YJV

Contact opnemen
150 Sq mm XLPE PVC Electrical Cable LV Multi Core CE IEC Certification

150 Sq mm XLPE PVC Electrical Cable LV Multi Core CE IEC Certification

Contact opnemen
Rigid XLPE Insulated 120 Sq MM Cable Black Outer Sheath Color YAXV-R

Rigid XLPE Insulated 120 Sq MM Cable Black Outer Sheath Color YAXV-R

Contact opnemen
Transmission Line XLPE LT Power Cable 95 Sq MM Cross Section Area

Transmission Line XLPE LT Power Cable 95 Sq MM Cross Section Area

Contact opnemen
70 Sq mm Concentric Conductor XLPE Insulated Power Cable Eco Friendly YJV N2XCY

70 Sq mm Concentric Conductor XLPE Insulated Power Cable Eco Friendly YJV N2XCY

Contact opnemen
Insulated High Voltage XLPE Underground Cable For Outside Power Distribution

Insulated High Voltage XLPE Underground Cable For Outside Power Distribution

Contact opnemen
21/35 kV Medium voltage AL/XLPE/CWS/PVC Electric cable with the concentric conductor screen

21/35 kV Medium voltage AL/XLPE/CWS/PVC Electric cable with the concentric conductor screen

Contact opnemen
Three core XLPE Insulated 12KV/20kV Power Cable Stranded Aluminum Conductor

Three core XLPE Insulated 12KV/20kV Power Cable Stranded Aluminum Conductor

Contact opnemen
8.7/15kV medium voltage XLPE Insulated Power cable copper wire screen conductor

8.7/15kV medium voltage XLPE Insulated Power cable copper wire screen conductor

Contact opnemen
producten
DETAILS VAN DE PRODUCTEN
Producten

XLPE geïsoleerde kabel

PVC geïsoleerde kabel

minerale geïsoleerde kabel

gepantserde elektrokabel

Multicore Controlekabel

enige kerndraad

Beschermde Instrumentenkabel

lage rook nul halogeenkabel

Brandwerende kabel

Vlam - vertragerskabel

Rubber Flexibele Kabel

lucht gebundelde kabel

Naakte Leider

flexibele elektrokabel

zonnepv kabel

Geprefabriceerde Takkabel

Hoge temperatuur kabel

koper bekleed aluminium draad

Flexibele Lassenkabel

de kabel van de lassentoorts
3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring
  • Naam
  • Naam
  • Naam
  • Naam
3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring
MOQ: 500
Prijs: USD 1-100 Per Meter
Standaardverpakking: Ijzer-houten trommel of Houten trommel
Leveringstermijn: 15 dagen
Betalingswijze: L/C, T/T, Western Union, MoneyGram
Toeleveringskapaciteit: 1000KM PER MAAND
Gedetailleerde informatie
Productbeschrijving
Gedetailleerde informatie
Plaats van herkomst
China
Merknaam
QINGDAO YICABLE CABLE
Certificering
IEC/CE/KEMA
Nominale spanning:
0.6/1kV
Dirigent Type:
Vastgelopen Leider (Klasse 2)
Kernteken:
Aantal of Kleurenstrook
Buigende straal:
6D cirkelleiders
Trommellengte:
500m of vanaf verzoek
Max. Werkende Temperatuur:
90℃
Min. bestelaantal:
500
Prijs:
USD 1-100 Per Meter
Verpakking Details:
Ijzer-houten trommel of Houten trommel
Levertijd:
15 dagen
Betalingscondities:
L/C, T/T, Western Union, MoneyGram
Levering vermogen:
1000KM PER MAAND
Markeren

xlpe electrical cable

,

cross linked polyethylene cable

Productbeschrijving

3 Core Copper Low Voltage Power Cables For Industrial Wiring and Mains Distribution

Applications: Industrial wiring and mains distribution. Can be laid direct in the ground, or in ducts, clipped to surface, on trays or in free air.



CONSTRUCTION



Conductor : Single, Two, Three, Four and Five core cables. Stranded plain copper conductors Insulation : XLPE insulated, cores laid up, extruded PVC bedding, galvanised steel wire armoured (Aluminium wires for single cores) and PVC sheathed.



STANDARD COLOURS



Cores : Single-core- Red or Black 2-core- Red and Black 3-core- Red, Yellow and Blue 4-core- Red, Yellow, Blue and Black 5-core- Red, Yellow, Blue, Black and Green/Yellow As per New Harmonised Code Single-core- Brown or Blue 2-core- Brown and Blue 3-core- Brown, Black and Grey 4-core- Brown, Black Grey and Blue 5-core- Brown, Black, Grey, Green/Yellow and Blue



PROPERTY:



1.The highest allowed operating temperature of conductor for long-term working is 90 degrees. 2.In short circuit (Max long term is no more than 5 seconds),the highest temperature for conductor is no more than 250 degrees. 3.The cable is laid without horizontal drop limit. The environment temperature should be no lower than 0 when lay. Otherwise it should be preheated. 4.Excellent electrical performance, resistance to chemical corrosion. 5.They can stand advisable traction when laid. They can stand traction from Outside. Left low smoke halogen-free after burned. Retard the burning of the cabl




Ordering Advice

Rated Voltage
Application Standard: IEC/BS/UL/GB
Number of Cores
Conductor Size & Construction
Type of Insulation
Armored or unarmored. If armor, the armor type & material
The Requirement of Sheath
Length of Cable & Packing Requirement
Other Requirement


3 Core Copper Low Voltage XLPE Insulated Power Cable For Industrial Wiring 0
